art10m's BookStack Hacks
<head>
<!-- ============================================================================
BOOKSTACK CUSTOM HEAD CONFIGURATION
This file contains custom styles, scripts, and integrations for BookStack:
- Typography and layout adjustments (zoom, colors, spacing)
- CodeMirror 6 line wrapping for code blocks
- Markdown-it configuration (soft line breaks)
- MathJax integration for LaTeX math rendering
- Mermaid diagram rendering with theme synchronization
- Light/Dark mode toggle button (works for both guests and logged-in users)
============================================================================ -->
<!-- ==========================================================================
CONSOLIDATED STYLES
========================================================================== -->
<style>
/* --------------------------------------------------------------------------
DETAILS ELEMENT SPACING
Ensures proper bottom margin for the last child inside <details> elements
-------------------------------------------------------------------------- */
.page-content details > *:last-child {
margin-bottom: .2em;
}
/* --------------------------------------------------------------------------
BLOCKQUOTE ADJUSTMENTS
- Adds consistent vertical spacing for first/last children
- Disables overflow scrolling to prevent unwanted scrollbars
-------------------------------------------------------------------------- */
.content-wrap blockquote > :last-child {
margin-bottom: .3em;
}
.content-wrap blockquote > :first-child {
margin-top: .3em;
}
.content-wrap blockquote {
overflow: visible;
overflow-x: visible;
overflow-y: visible;
}
/* --------------------------------------------------------------------------
PAGE CONTENT ZOOM AND TYPOGRAPHY
- Applies 1.15x zoom to page content for better readability
- Compensates heading size with 0.9x zoom to maintain visual hierarchy
-------------------------------------------------------------------------- */
.page-content {
zoom: 1.15;
}
.page-content h1,
.page-content h2,
.page-content h3,
.page-content h4,
.page-content h5,
.page-content h6 {
zoom: .9;
}
/* --------------------------------------------------------------------------
COLOR SCHEME: LIGHT MODE
- Dark text on light background for optimal contrast
- Slightly muted headings for visual hierarchy
-------------------------------------------------------------------------- */
html .page-content {
color: hsl(0 0% 10%);
}
html .page-content h1,
html .page-content h2,
html .page-content h3,
html .page-content h4,
html .page-content h5,
html .page-content h6 {
color: hsl(0 0% 30%);
}
/* --------------------------------------------------------------------------
COLOR SCHEME: DARK MODE
- Light text on dark background
- Adjusted heading colors for dark theme
- Muted gutter colors for CodeMirror editor
-------------------------------------------------------------------------- */
html.dark-mode .page-content {
color: hsl(0 0% 90%);
}
html.dark-mode .page-content h1,
html.dark-mode .page-content h2,
html.dark-mode .page-content h3,
html.dark-mode .page-content h4,
html.dark-mode .page-content h5,
html.dark-mode .page-content h6 {
color: hsl(0 0% 70%);
}
html.dark-mode .ͼo .cm-gutters {
color: hsl(0 0% 33%);
}
/* --------------------------------------------------------------------------
CODEMIRROR EDITOR STYLING
Removes border-radius for a cleaner, squared appearance
-------------------------------------------------------------------------- */
.page-content .cm-editor {
border-radius: 0;
}
/* --------------------------------------------------------------------------
MERMAID DIAGRAM CONTAINER
- Dashed border for visual identification during development/editing
- Centered layout with horizontal scroll for large diagrams
-------------------------------------------------------------------------- */
.mermaid-container {
border: 1px dashed #4238ff !important;
}
.mermaid {
margin: 1em auto;
overflow-x: auto;
text-align: center;
}
.mermaid svg {
max-width: 100%;
height: auto;
display: inline-block;
}
/* --------------------------------------------------------------------------
THEME TOGGLE BUTTON (FIXED POSITION)
- Positioned at bottom-left corner for easy access
- Circular button with hover/active states
- Semi-transparent by default, full opacity on hover
-------------------------------------------------------------------------- */
.theme-toggle-fixed {
position: fixed;
bottom: 20px;
left: 20px;
z-index: 9999;
background: var(--color-primary, #206ea7);
border: none;
border-radius: 50%;
width: 44px;
height: 44px;
cursor: pointer;
box-shadow: 0 2px 8px rgba(0, 0, 0, 0.25);
display: flex;
align-items: center;
justify-content: center;
transition: transform 0.2s ease, box-shadow 0.2s ease, opacity 0.2s ease;
opacity: 0.7;
}
.theme-toggle-fixed:hover {
transform: scale(1.1);
box-shadow: 0 4px 12px rgba(0, 0, 0, 0.35);
opacity: 1;
}
.theme-toggle-fixed:active {
transform: scale(0.95);
}
.theme-toggle-fixed svg {
width: 22px;
height: 22px;
fill: #ffffff;
}
</style>
<!-- ==========================================================================
MATHJAX CONFIGURATION
Enables LaTeX math rendering with $ for inline and $$ for display math
========================================================================== -->
<script>
window.MathJax = {
tex: {
inlineMath: [['$', '$']],
displayMath: [['$$', '$$']]
}
};
</script>
<script id="MathJax-script" async src="https://cdn.jsdelivr.net/npm/mathjax@4/tex-mml-chtml.js"></script>
<!-- ==========================================================================
BOOKSTACK EVENT LISTENERS AND THEME TOGGLE
- CodeMirror 6 line wrapping configuration
- Markdown-it soft line break configuration
- Light/Dark mode toggle for guests and logged-in users
========================================================================== -->
<script>
(function () {
'use strict';
/* ========================================================================
SHARED THEME STORAGE KEY
Used by both the toggle button and Mermaid for consistent theme state
======================================================================== */
var THEME_STORAGE_KEY = 'bookstack-guest-dark-mode';
// Expose storage key globally for the Mermaid module to access
window.BOOKSTACK_THEME_STORAGE_KEY = THEME_STORAGE_KEY;
/* ========================================================================
CODEMIRROR 6: LINE WRAPPING FOR CODE BLOCKS
Listens for the CM6 pre-init event and enables line wrapping
for content code blocks to prevent horizontal scrolling
======================================================================== */
window.addEventListener('library-cm6::pre-init', function (event) {
var detail = event.detail;
var config = detail.editorViewConfig;
var EditorView = detail.libEditorView;
// Only apply line wrapping to content code blocks (not the main editor)
if (detail.usage === 'content-code-block') {
config.extensions.push(EditorView.lineWrapping);
}
});
/* ========================================================================
MARKDOWN-IT: SOFT LINE BREAKS
Configures the Markdown editor to convert single newlines to <br> tags
(GFM-style line breaks)
======================================================================== */
window.addEventListener('editor-markdown::setup', function (event) {
event.detail.markdownIt.set({breaks: true});
});
/* ========================================================================
LIGHT/DARK MODE TOGGLE BUTTON
Features:
- Works for both guests (localStorage) and logged-in users (server-side)
- Applies saved preference immediately to prevent flash of wrong theme
- Detects system color scheme preference as fallback for guests
======================================================================== */
/**
* Checks if the guest has dark mode enabled based on localStorage
* Falls back to system preference if no stored value exists
* @returns {boolean} True if dark mode should be enabled
*/
function isGuestDarkModeEnabled() {
var stored = localStorage.getItem(THEME_STORAGE_KEY);
if (stored !== null) {
return stored === 'true';
}
// Fallback: Check system color scheme preference
return window.matchMedia && window.matchMedia('(prefers-color-scheme: dark)').matches;
}
/**
* Determines if the current user is logged in
* Checks for CSRF token AND user menu elements (both required)
* @returns {boolean} True if user is logged in
*/
function isUserLoggedIn() {
var csrfMeta = document.querySelector('meta[name="csrf-token"]');
var hasToken = csrfMeta && csrfMeta.getAttribute('content');
var hasUserMenu = document.querySelector('.dropdown-container [data-shortcut="favourites_view"]')
|| document.querySelector('[href*="/logout"]');
return !!(hasToken && hasUserMenu);
}
/**
* Applies the theme by toggling the 'dark-mode' class on <html>
* @param {boolean} isDark - Whether to enable dark mode
*/
function applyTheme(isDark) {
if (isDark) {
document.documentElement.classList.add('dark-mode');
} else {
document.documentElement.classList.remove('dark-mode');
}
}
// ---------------------------------------------------------------------------
// IMMEDIATE THEME APPLICATION (before DOMContentLoaded)
// Prevents flash of wrong theme by applying saved preference early
// ---------------------------------------------------------------------------
var currentlyDark = document.documentElement.classList.contains('dark-mode');
var guestPref = localStorage.getItem(THEME_STORAGE_KEY);
if (guestPref !== null) {
if (!currentlyDark && guestPref === 'true') {
document.documentElement.classList.add('dark-mode');
} else if (guestPref === 'false' && currentlyDark) {
document.documentElement.classList.remove('dark-mode');
}
}
// ---------------------------------------------------------------------------
// CREATE TOGGLE BUTTON (after DOM is ready)
// ---------------------------------------------------------------------------
document.addEventListener('DOMContentLoaded', function () {
var isDarkMode = document.documentElement.classList.contains('dark-mode');
var loggedIn = isUserLoggedIn();
// SVG icons for sun (light mode) and moon (dark mode)
var sunIcon = '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 24 24"><path d="M20 15.31 23.31 12 20 8.69V4h-4.69L12 .69 8.69 4H4v4.69L.69 12 4 15.31V20h4.69L12 23.31 15.31 20H20zM12 18c-3.31 0-6-2.69-6-6s2.69-6 6-6 6 2.69 6 6-2.69 6-6 6"/></svg>';
var moonIcon = '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 24 24"><path d="M12 3a9 9 0 1 0 9 9c0-.46-.04-.92-.1-1.36a5.389 5.389 0 0 1-4.4 2.26 5.403 5.403 0 0 1-3.14-9.8c-.44-.06-.9-.1-1.36-.1z"/></svg>';
// Create the toggle button element
var button = document.createElement('button');
button.className = 'theme-toggle-fixed';
button.type = 'button';
button.title = isDarkMode ? 'Activate Light Mode' : 'Activate Dark Mode';
button.innerHTML = isDarkMode ? sunIcon : moonIcon;
// Handle click: server-side for logged-in users, client-side for guests
button.addEventListener('click', function () {
if (loggedIn) {
// Logged-in users: Submit form to BookStack's preference endpoint
var csrfToken = '';
var csrfMeta = document.querySelector('meta[name="csrf-token"]');
if (csrfMeta) {
csrfToken = csrfMeta.getAttribute('content') || '';
}
var form = document.createElement('form');
form.method = 'POST';
form.action = '/preferences/toggle-dark-mode';
form.innerHTML =
'<input type="hidden" name="_token" value="' + csrfToken + '">' +
'<input type="hidden" name="_method" value="PATCH">' +
'<input type="hidden" name="_return" value="' + window.location.href + '">';
document.body.appendChild(form);
form.submit();
} else {
// Guests: Toggle theme client-side and save to localStorage
var nowDark = document.documentElement.classList.contains('dark-mode');
var newMode = !nowDark;
applyTheme(newMode);
localStorage.setItem(THEME_STORAGE_KEY, newMode.toString());
// Update button appearance
button.innerHTML = newMode ? sunIcon : moonIcon;
button.title = newMode ? 'Activate Light Mode' : 'Activate Dark Mode';
}
});
document.body.appendChild(button);
});
})();
</script>
<!-- ==========================================================================
MERMAID DIAGRAM RENDERING (ES MODULE)
Features:
- Automatic detection of mermaid code blocks (multiple selector formats)
- Theme synchronization with BookStack's dark/light mode
- Uses shared localStorage key with theme toggle button
- Theme changes apply on next page load (no live re-rendering)
========================================================================== -->
<script type="module">
import mermaid from "https://cdn.jsdelivr.net/npm/mermaid@11/dist/mermaid.esm.min.mjs";
// Use the shared storage key from the main script
const STORAGE_KEY = window.BOOKSTACK_THEME_STORAGE_KEY || "bookstack-guest-dark-mode";
/* ==========================================================================
THEME DETECTION UTILITIES
========================================================================== */
/**
* Checks if BookStack is currently in dark mode
* @returns {boolean} True if 'dark-mode' class is present on <html>
*/
function isBookStackDarkMode() {
return document.documentElement.classList.contains("dark-mode");
}
/**
* Retrieves the stored theme preference from localStorage
* @returns {boolean|null} true = dark, false = light, null = not set
*/
function getStoredThemeIsDark() {
const stored = localStorage.getItem(STORAGE_KEY);
if (stored === null) return null;
return stored === "true";
}
/**
* Saves the theme preference to localStorage
* @param {boolean} isDark - Whether dark mode is enabled
*/
function storeThemeIsDark(isDark) {
localStorage.setItem(STORAGE_KEY, isDark ? "true" : "false");
}
/**
* Determines the Mermaid theme based on current BookStack mode
* Uses actual DOM state (dark-mode class) for accurate theme selection
* @returns {string} Mermaid theme name ("dark" or "default")
*/
function getMermaidTheme() {
return isBookStackDarkMode() ? "dark" : "default";
}
/* ==========================================================================
MERMAID INITIALIZATION
Disabled auto-start to allow manual control over rendering
========================================================================== */
mermaid.initialize({
startOnLoad: false,
securityLevel: "strict",
theme: getMermaidTheme()
});
/* ==========================================================================
DOM UTILITIES FOR MERMAID CODE BLOCKS
========================================================================== */
/**
* Finds all elements containing Mermaid diagram source code
* Supports multiple code block formats used by different editors
* @returns {HTMLElement[]} Array of source elements
*/
function findMermaidSources() {
const selectors = [
"pre.mermaid",
"pre > code.language-mermaid",
"pre > code.lang-mermaid",
"code.language-mermaid"
];
const nodes = Array.from(document.querySelectorAll(selectors.join(",")));
// Normalize to parent <pre> element when applicable
return nodes.map(n =>
(n.tagName.toLowerCase() === "code" && n.parentElement?.tagName.toLowerCase() === "pre")
? n.parentElement
: n
);
}
/**
* Extracts the text content (Mermaid code) from a source element
* @param {HTMLElement} node - The source element
* @returns {string} The trimmed Mermaid code
*/
function extractCodeFromNode(node) {
const codeEl = node.tagName.toLowerCase() === "pre"
? (node.querySelector("code") || node)
: node;
return (codeEl.textContent || "").trim();
}
/**
* Replaces the original code block with a Mermaid container div
* Initially hidden to prevent flash of unstyled content
* @param {HTMLElement} originalNode - The original code block element
* @param {string} code - The Mermaid diagram code
* @returns {HTMLElement} The new container element
*/
function replaceWithContainer(originalNode, code) {
const container = document.createElement("div");
container.className = "mermaid";
container.textContent = code;
container.style.visibility = "hidden";
originalNode.replaceWith(container);
return container;
}
/* ==========================================================================
PAGE READY DETECTION
========================================================================== */
/**
* Waits for the page to be fully loaded and rendered
* Uses multiple techniques to ensure DOM is stable:
* 1. Wait for 'load' event (or skip if already complete)
* 2. Wait for two animation frames (ensures layout is calculated)
* 3. Additional timeout for any async CSS/font loading
*/
async function waitForPageReady() {
// Wait for window load event
await new Promise(resolve => {
if (document.readyState === "complete") return resolve();
window.addEventListener("load", () => resolve(), {once: true});
});
// Wait for layout stabilization (two animation frames)
await new Promise(r => requestAnimationFrame(() => requestAnimationFrame(r)));
// Additional buffer for async resources
await new Promise(r => setTimeout(r, 150));
}
/* ==========================================================================
MAIN RENDERING FUNCTION
========================================================================== */
/**
* Main entry point: finds, transforms, and renders all Mermaid diagrams
* Theme is determined once at render time and applied consistently
* Theme changes will take effect on next page load
*/
async function renderAllMermaid() {
const sources = findMermaidSources();
// Even without diagrams, ensure theme state is stored for consistency
if (!sources.length) {
await waitForPageReady();
storeThemeIsDark(isBookStackDarkMode());
return;
}
// Transform code blocks into Mermaid containers
const containers = [];
for (const src of sources) {
const code = extractCodeFromNode(src);
if (!code) continue;
const container = replaceWithContainer(src, code);
// Store original code for potential future use
container.setAttribute("data-original-code", code);
containers.push(container);
}
await waitForPageReady();
// Render all diagrams with the current theme
for (const el of containers) {
try {
await mermaid.run({nodes: [el]});
el.style.visibility = "visible";
} catch (e) {
el.style.visibility = "visible";
console.error("Mermaid render failed for element:", el, e);
}
}
// Store current theme state for next page load
storeThemeIsDark(isBookStackDarkMode());
}
// Start rendering process
renderAllMermaid();
</script>
functions.php
/opt/bookstack/bookstack/www/themes/custom/functions.php
<?php
// Import the ThemeEvents class which contains event constants for the theming system
use BookStack\Theming\ThemeEvents;
// Import the Theme facade to register event listeners
use BookStack\Facades\Theme;
/**
* Register a listener for the CommonMark environment configuration event.
* This hook is triggered when BookStack sets up the Markdown parser.
*
* CommonMark is the Markdown parsing library used by BookStack.
*/
Theme::listen(ThemeEvents::COMMONMARK_ENVIRONMENT_CONFIGURE, function ($environment) {
// Merge custom configuration into the CommonMark environment
$environment->mergeConfig([
'renderer' => [
// Convert soft line breaks (single newlines) into <br> HTML tags
// By default, CommonMark ignores single newlines in Markdown.
// This setting makes single line breaks visible in the rendered output,
// which is useful for preserving line formatting in user content.
'soft_break' => "<br>",
]
]);
// Return the modified environment so other listeners can further customize it
return $environment;
});
oEmbeds in <head>
<style>
.auto-embed {
position: relative;
width: 100%;
max-width: 100%;
margin: 1rem 0;
overflow: hidden;
background: #000;
}
.auto-embed.video {
aspect-ratio: 16/9;
}
.auto-embed.audio {
aspect-ratio: 16/5;
}
.auto-embed.code {
aspect-ratio: 4/3;
min-height: 400px;
}
.auto-embed.square {
aspect-ratio: 1/1;
}
.auto-embed iframe {
position: absolute;
inset: 0;
width: 100%;
height: 100%;
border: 0;
}
</style>
<script>
document.addEventListener('DOMContentLoaded', () => {
const providers = [
// 🎬 Video
{
regex: /youtu(?:be\.com\/watch\?v=|\.be\/)([\w-]+)/i,
embed: id => `https://www.youtube-nocookie.com/embed/${id}`, type: 'video'
},
{
regex: /vimeo\.com\/(\d+)/i,
embed: id => `https://player.vimeo.com/video/${id}`, type: 'video'
},
{
regex: /dailymotion\.com\/video\/([\w-]+)/i,
embed: id => `https://www.dailymotion.com/embed/video/${id}`, type: 'video'
},
{
regex: /twitch\.tv\/videos\/(\d+)/i,
embed: id => `https://player.twitch.tv/?video=${id}&parent=${location.hostname}`, type: 'video'
},
{
regex: /twitch\.tv\/([\w-]+)$/i,
embed: id => `https://player.twitch.tv/?channel=${id}&parent=${location.hostname}`, type: 'video'
},
{
regex: /loom\.com\/share\/([\w-]+)/i,
embed: id => `https://www.loom.com/embed/${id}`, type: 'video'
},
{
regex: /streamable\.com\/([\w-]+)/i,
embed: id => `https://streamable.com/e/${id}`, type: 'video'
},
// 🎵 Audio
{
regex: /open\.spotify\.com\/(track|album|playlist|episode)\/([\w-]+)/i,
embed: (t, id) => `https://open.spotify.com/embed/${t}/${id}`, type: 'audio'
},
{
regex: /soundcloud\.com\/([\w-]+\/[\w-]+)/i,
embed: path => `https://w.soundcloud.com/player/?url=https://soundcloud.com/${path}&color=%23ff5500&auto_play=false&hide_related=true&show_comments=false&show_user=true&show_reposts=false&show_teaser=false`,
type: 'audio'
},
// 💻 Code - CodePen
// ✅ CodePen v2.0 Editor-Format (DIREKTES IFRAME!)
{
regex: /codepen\.io\/editor\/([\w-]+)\/pen\/([\w-]+)/i,
embed: (user, penId) => `https://codepen.io/editor/${user}/embed/${penId}?default-tab=html%2Cresult&theme-id=dark&editable=true`,
type: 'code'
},
// ✅ Klassisches CodePen-Format
{
regex: /codepen\.io\/([\w-]+)\/(?:pen|full|details)\/([\w-]+)/i,
embed: (user, penId) => `https://codepen.io/${user}/embed/${penId}?default-tab=html%2Cresult&theme-id=dark&editable=true`,
type: 'code'
},
// Andere Code-Plattformen
{
regex: /codesandbox\.io\/s\/([\w-]+)/i,
embed: id => `https://codesandbox.io/embed/${id}`, type: 'code'
},
{
regex: /stackblitz\.com\/edit\/([\w-]+)/i,
embed: id => `https://stackblitz.com/edit/${id}?embed=1`, type: 'code'
},
{
regex: /jsfiddle\.net\/([\w-]+\/[\w-]+)/i,
embed: path => `https://jsfiddle.net/${path}/embedded/result,js,html,css/`, type: 'code'
},
{
regex: /gist\.github\.com\/([\w-]+)\/([\w-]+)/i,
embed: (u, id) => `data:text/html,<script src="https://gist.github.com/${u}/${id}.js"><\/script>`,
type: 'code'
},
// 🗺️ Maps & Design
{
regex: /figma\.com\/(file|design)\/([\w-]+)/i,
embed: (t, id) => `https://www.figma.com/embed?embed_host=bookstack&url=https://www.figma.com/${t}/${id}`,
type: 'code'
},
{
regex: /google\.com\/maps\/embed\?pb=([^&\s]+)/i,
embed: pb => `https://www.google.com/maps/embed?pb=${pb}`, type: 'video'
},
];
document.querySelectorAll('p').forEach(p => {
const text = p.textContent.trim();
if (!/^https?:\/\/\S+$/i.test(text)) return;
for (const {regex, embed, type} of providers) {
const match = text.match(regex);
if (!match) continue;
const src = embed(...match.slice(1));
p.outerHTML = `<div class="auto-embed ${type}"><iframe src="${src}" allowfullscreen loading="lazy" allowtransparency="true"></iframe></div>`;
return;
}
});
});
</script>
And this must be added to docker-compose.yml
Under environment:
- ALLOWED_IFRAME_SOURCES=https://*.codepen.io https://codepen.io https://*.jsfiddle.net https://jsfiddle.net https://*.codesandbox.io https://codesandbox.io https://open.spotify.com https://gist.github.com https://*.youtube.com https://youtube.com https://www.youtube-nocookie.com https://*.vimeo.com https://player.vimeo.com https://*.dailymotion.com https://*.twitch.tv https://player.twitch.tv https://clips.twitch.tv https://*.tiktok.com https://*.loom.com https://*.wistia.com https://fast.wistia.net https://streamable.com https://*.vidyard.com https://rumble.com https://*.soundcloud.com https://w.soundcloud.com https://embed.music.apple.com https://*.deezer.com https://widget.deezer.com https://*.bandcamp.com https://*.mixcloud.com https://*.audiomack.com https://anchor.fm https://*.transistor.fm https://*.stackblitz.com https://*.replit.com https://*.glitch.com https://jsbin.com https://*.observablehq.com https://carbon.now.sh https://asciinema.org https://platform.twitter.com https://*.instagram.com https://*.reddit.com https://*.linkedin.com https://assets.pinterest.com https://*.figma.com https://*.canva.com https://docs.google.com https://*.pitch.com https://prezi.com https://*.slideshare.net https://speakerdeck.com https://maps.google.com https://*.openstreetmap.org https://*.notion.so https://*.notion.site https://*.airtable.com https://*.typeform.com https://form.typeform.com https://calendly.com https://*.miro.com https://excalidraw.com https://*.diagrams.net https://whimsical.com https://*.lottiefiles.com https://lottie.host https://*.sketchfab.com
https://www.youtube.com/watch?v=UclrVWafRAI
